AT4764V Datalogger | Anbai Instruments

Compare

AT4108

Sensor: Thermocouple:J/K/T
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.1℃
Channels: 8 channels;

Compare

AT4116

Sensor: Thermocouple:J/K/T
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.1℃
Channels: 16channels;

Compare

AT4202

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: 0.2%+1℃
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.1℃
Channels: 2 channels

Compare

AT4204

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.1℃
Channels: 4 channels

Compare

AT4208

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.1℃
Channels: 8 channels

Compare

AT4310

Sensor: RTD:PT100/Cu50, thermocouple:J/K/T/E/S/N/B/R
Accuracy: RTD 0.2℃±2，thermocouple：0.5%±0.5℃ (varying depend on sensor)
Range: -200℃～1300℃ (varying depend on sensor)
Resolution: 0.1℃
Channels: RTD 5 channels; thermocouple 10 channels; scan channel can off arbitrarily

Compare

AT4320

Sensor: RTD:PT100/Cu50, thermocouple:J/K/T/E/S/N/B/R
Accuracy: RTD0.2℃±2，thermocouple：0.5%±0.5℃ (varying depend on sensor)
Range: -200℃～1300℃ (varying depend on sensor)
Resolution: 0.1℃
Channels: RTD 10 channels; thermocouple 20 channels; scan channel can off arbitrarily

Compare

AT4340

Sensor: RTD:PT100/Cu50, thermocouple:J/K/T/E/S/N/B/R
Accuracy: RTD 0.2℃±2，thermocouple：0.5%±0.5℃ (varying depend on sensor)
Range: -200℃～1300℃ (varying depend on sensor)
Resolution: 0.1℃
Channels: RTD20 channels; thermocouple 40 channels; scan channel can off arbitrarily

Compare

AT4508

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.1℃
Channels: 8 channels; 128 channels are available

Compare

AT4516

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.1℃
Channels: 16 channel; 128 channels are available

Compare

AT4524

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.1℃
Channels: 24 channels; 128 channels are available

Compare

AT4532

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.1℃
Channels: 32 channels; 128 channels are available

Compare

AT4708

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.01℃
Channels: 8 channels;

Compare

AT4708H

Sensor: J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃
Resolution: 0.01℃
Channels: 8 channels

Compare

AT4716H

Sensor: J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃
Resolution: 0.01℃
Channels: 16 channels

Compare

AT4724H

Sensor: J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃（
Resolution: 0.01℃
Channels: 24 channels

Compare

AT4732H

Sensor: J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃
Resolution: 0.01℃
Channels: 32 channel

Compare

AT4808

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.1℃
Channels: 8 channels; 128 channels are available

Compare

AT4724

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.01℃
Channels: 24 channels;

Compare

AT4732

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.01℃
Channels: 32 channels;

Compare

AT4740

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.01℃
Channels: 40 channels;

Compare

AT4748

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.01℃
Channels: 48 channels

Compare

AT4756

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.01℃
Channels: 56 channels;

Compare

AT4764

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.01℃
Channels: 64 channels;

Compare

AT4708V

Sensor: Thermocouple:J/K/T/E/S/N/B/R,PT100,CU50，DCV
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌；PT100: ±0.6℃ CU50 : ±0.6℃
Range: -200℃~1800℃ (variation depend on sensor)
DCV:100mV~100V
Resolution: 0.01℃

Compare

AT4716V

Sensor: Thermocouple:J/K/T/E/S/N/B/R,PT100,CU50，DCV
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌；PT100: ±0.6℃ CU50 : ±0.6℃
Range: -200℃~1800℃ (variation depend on sensor)
DCV:100mV~100V
Resolution: 0.01℃

Compare

AT4724V

Sensor: Thermocouple:J/K/T/E/S/N/B/R,PT100,CU50，DCV
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌；PT100: ±0.6℃ CU50 : ±0.6℃
Range: -200℃~1800℃ (variation depend on sensor)，
DCV:100mV~100V
Resolution: 0.01℃

Compare

AT4732V

Sensor: Thermocouple:J/K/T/E/S/N/B/R,PT100,CU50，DCV
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌；PT100: ±0.6℃ CU50 : ±0.6℃
Range: -200℃~1800℃ (variation depend on sensor)，
DCV:100mV~100V
Resolution: 0.01℃

Compare

AT4740V

Sensor: Thermocouple:J/K/T/E/S/N/B/R,PT100,CU50，DCV
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌；PT100: ±0.6℃ CU50 : ±0.6℃
Range: -200℃~1800℃ (variation depend on sensor)
DCV:100mV~100V
Resolution: 0.01℃

Compare

AT4748V

Sensor: Thermocouple:J/K/T/E/S/N/B/R,PT100,CU50，DCV
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌；PT100: ±0.6℃ CU50 : ±0.6℃
Range: -200℃~1800℃ (variation depend on sensor)
DCV:100mV~100V
Resolution: 0.01℃

Compare

AT4756V

Sensor: Thermocouple:J/K/T/E/S/N/B/R,PT100,CU50，DCV
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌；PT100: ±0.6℃ CU50 : ±0.6℃
Range: -200℃~1800℃ (variation depend on sensor)
DCV:100mV~100V
Resolution: 0.01℃

Compare

AT4716

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.01℃
Channels: 16 channels;

Compare

AT4816

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.1℃
Channels: 16 channels; 128 channels are available

Compare

AT4824

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.1℃
Channels: 24 channels; 128 channels are available

Compare

AT4832

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.1℃
Channels: 32 channels; 128 channels are available

Compare

AT4540

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.1℃
Channels: 40 channels; 128 channels are available

Compare

AT4548

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.1℃
Channels: 48 channels; 128 channels are available

Compare

AT4556

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.1℃
Channels: 56 channels; 128 channels are available

Compare

AT4564

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.1℃
Channels: 64 channels; 128 channels are available

Compare

AT4572

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.1℃
Channels: 72 channels; 128 channels are available

Compare

AT4580

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.1℃
Channels: 80 channels; 128 channels are available

Compare

AT4588

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.1℃
Channels: 88 channels; 128 channels are available

Compare

AT4596

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.1℃
Channels: 96 channels; 128 channels are available

Compare

AT45104

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.01℃
Channels: 104 channels;

Compare

AT45112

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.1℃
Channels: 112 channels; 128 channels are available

Compare

AT45120

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.1℃
Channels: 120 channels; 128 channels are available

Compare

AT45128

Sensor: Thermocouple:J/K/T/E/S/N/B/R
Accuracy: ‌±0.2% ±2 Digits (Excluding Thermocouple)‌
Range: -200℃~1800℃ (variation depend on sensor)
Resolution: 0.1℃
Channels: 128 channels; 128 channels are available

Sensor	Thermocouple:J/K/T/E/S/N/B/R,PT100,CU50，DCV
Accuracy	‌±0.2% ±2 Digits (Excluding Thermocouple)‌；PT100: ±0.6℃ CU50 : ±0.6℃
Range	-200℃~1800℃ (variation depend on sensor) DCV:100mV~100V
Resolution	0.01℃
Channels	64 channels;
Speed	fast: 500ms/channel, slow: 1s/channel
Correction	Error correction for each channel
Comparator	high & low beep function for each channel
Interface	RS232C, U-disc, Type-c， LAN
Software	ATS45 data acquisition software
Cold Junction	Accuracy: 0.5℃
Other Functions	TFT-LCD True color display, broken thermocouple check function
Power Supply	V: 100V-240VAC Fre：47.5-52.5Hz Power：10VA
Dimension & Weight	294x130x316mm weight：3kg
Accessories	Thermocouple: 2m long, 8 sets × 8 pieces (total 64) TYPE-C Communication Cable ； ATS45 Data Acquisition Software 。
