| Output voltage range | 6V/CH |
| Current range | 1A/CH |
| Maximum output power | 6W/CH |
| Number of channels | 24 |
| Range | 0~1A |
| Voltage setting resolution | 0.01mV |
| Voltage readback resolution | 0.01mV |
| Current setting resolution | 0.01mA (1mA Range) |
| Current readback resolution | 0.01μA (1mA Range) |
| Voltage setting/readback accuracy | ±0.01%，±0.1mv |
| Current setting/readback accuracy | ±0.05%，±0.1mA |
| Ripple | <2mV rms |
| ripple current | <2mA rms |
| Load adjustment rate - output voltage | <0.01%FS |
| Load adjustment rate - output current | <0.01%FS |
| Power adjustment rate - output voltage | <0.01%FS |
| Power adjustment rate - output current | <0.01%FS |
| temperature coefficient | <20 ppm/℃ |
| Voltage rise time (no-load) | <100us |
| Voltage rise time (full load) | <100us |
| Voltage drop time (no-load) | <100us |
| Voltage drop time (full load) | <100us |
| dynamic response time | <50us |
| Voltage withstand (output to ground/output to output) | 1000VDC/1000VDC |
| interface | RS232 interface RS485 interface LAN interface |
| Power requirements | 200V-240VAC |
| Dimension | Standard 2U chassis/15KG |
| annex | Test line/power line/RS232 communication line |
