OVERVIEW
    The AT6750 is a ‌high-power programmable DC power supply with high precision‌, featuring a ‌full-color LCD screen‌ and a ‌full digital keypad‌, combined with the ‌Amber Instruments Operating System‌ for ‌clearer display and more convenient operation‌.

    Utilizing an ‌advanced topology (LLC/full-bridge)‌, the AT6750 programmable DC power supply achieves ‌high efficiency of ≥95%‌, reducing energy loss. It is ‌an ideal choice for industrial, research, and energy sector applications‌.
FEATURES
  • High-Performance Power Delivery‌
  • High-Power Stable Power Supply: 1500W Continuous Output Capability for Power-Hungry Equipment.
  • Precision High-Voltage Control: 1500V DC Regulated Output for Demanding Industrial Environments.
  • High-Efficiency Conversion: Advanced Topology (LLC/Full-Bridge) Implementation Achieving ≥95% Efficiency to Minimize Energy Wastage.
  • Safe and Reliable Operation: Comprehensive Protection Mechanisms (OVP/OCP/SCP) per International Standards.
SPECIFICATIONS
Output Voltage Range○
Voltage0-1500V
Electric current0-1A
Power1500W
‌efficiency‌87%
‌Line Regulation‌○
Voltage0.01% +2mV
Current0.01% +2mA
Load regulation rate○
Voltage0.01% +2mV
Current0.02% +5mA
Ripple○
Voltage100mV rms； p-p：400mVpp
Current6mA rms
Programming languageSCPI& Modbus (RTU)
Size483 (w)x89(H)x553 (L)
Weight15kg
DOCUMENTATION
DOCUMENTS
USER'S GUIDE CHINESE
ACCESSORIES
STANDARDS
NONE
OPTIONS
NONE
SOFTWARE
NONE
