AT682 High Resistance Meter
ACTIVE
8th Edition
RS232HANDLER
SCPI
DATA LOGGER
OVERVIEW
    The AT682 High Resistance Meter is an MCU controlled measuring instrument for direct readout of resistance and current. The voltage applied to the device under test (DUT) is programmable from 1 to 1000 volts. A pass/fail indicator provides a visual display of test results based on a preset limit.

    The AT682 High Resistance Meter is designed for measuring very high resistance and related parameters of insulation materials, electronic components, and electro-mechanical components.
FEATURES
  • High brightness, ultra-clear four-color VFD display, multiple parameters are displayed at the same time.
  • Comparator output: The sorting result can be output through the optional Handler interface and RS232C.
  • Adjustable sound and display: Users can set the GD/NG sound and adjust the display brightness according to their needs.
  • Shockproof sheath.
  • Built-in RS232C serial interface.
  • Fool-style menuless operation interface.
  • Optional Handler interface.
  • Optional RS485 interface.
  • Optional 500V, 500mA pre-charging interface
SPECIFICATIONS
ParametersLeakage current & insulation resistance
Output VoltageNC 1V~1000VDC
Accuracy<10G: 3% ≥10G: 5% ≥100G: 10%
Measurement Range10k-1TΩ(104~1012 Ω)
Display Max9999
RangeAutomatic & Manual
Speed55 times/s, 15 times/s, 3 times/s
Adjustmentshort-circuit reset full range
Result Displayshow, current, resistance, peak value, sorthing results
Charging Timer999.9s
Charging Current200mA max
Comparator30 sets record,, GD/NG beep: GD,NG, OFF setting
InterfaceRS-232C, Handler interface
Power SupplyVoltage:198VAC~240VAC Fre:50Hz Power :max 30VA
Dimension & Weight264*107*350mm / 5KG
AccessoriesATL507: Test fixture ; ATL801:RS232 cable
Other FunctionsVFD 4 color display, Keyboard lock, data hold function
APPLICATIONS
    Used for field test or timed test and destructive test.
    Test the insulation resistance and leakage current of switchgear, relays, motors, generators and cables.
    Insulation resistance measurement of capacitors and other electronic components and equipment.
    Dielectric materials and insulation resistance measurement of wires and cables, etc.
    The best solution for capacitor sorting machines.
DOCUMENTATION
DOCUMENTS
DATASHEET CHINESE
USER'S GUIDE ENGLISH

|

CHINESE
ACCESSORIES
STANDARDS

ATL108

ATL108

RS232通讯电缆

ATL507

ATL507

OPTIONS
NONE
SOFTWARE
AT682 Data Acquisition Software
Rev.A1.0

CHINESE

Application

FREEWARE

6.4MB

RAR
